VHPS-2000-FF

Steel Manual Stacker Fixed Forks/Legs 2,000 Lb. Capacity Black / Yellow

The manual stacker is designed to meet the most challenging tasks. Ideal for use in various workstation and workplace applications. Maintenance free and easy to use. The full height push handle allows for easy steering and excellent visibility through a welded mesh guard with an optional removable platform available. The Hydraulic hand pump is sturdy and compact to fit through standard doors. The forks are raised by manual hydraulic hand pump operation and released by a lever situated on the handle. The unit has two (2) rigid and two (2) swivel wheels standard.

  • Stacker design meets the most challenging tasks
  • Unique design is maintenance free and easy to use
  • Full height push handle allows for easy steering
  • Rolls on smooth casters for stable maneuvering
Total Ship Wt.(lbs.): 570 (only 1 package) Size: 27.375"W x 60.25"L x 78"H Color: Black / Yellow Non-Returnable

Uniform Capacity (lb.): 2000 Service Range (in.): 3-3/4 to 63 Fork Length (in.): 42-1/8
Lift per Handle Pump (in.): 3/4 Straddle Leg Minimum (in.): 34 (I.D) Straddle Leg Maximum (in.): 50 (I.D)
Fork Adjustment Minimum (in.): 6 (O.D) Fork Adjustment Maximum (in.): 24 (O.D) Rear Caster Quantity/Diameter/Width (in.): (2) 7 x 2
Rear Caster Type: Swivel with Brake Front Caster Quantity/Diameter/Width (in.): (2) 4 x 2-29/32 Front Caster Type: Rigid
Individual Fork Width (in.): 4 Horizontal Load Center (in.): 24

Quickship Item?

Quickship Item

Can It Ship UPS/FedEx?


LTL - Must Go Truck

Image Gallery

PDF Documents

Details For Model: VHPS-2000-FF
VHPS-2000-FF

Steel Manual Stacker Fixed Forks/Legs 2,000 Lb. Capacity Black / Yellow

The manual stacker is designed to meet the most challenging tasks. Ideal for use in various workstation and workplace applications. Maintenance free and easy to use. The full height push handle allows for easy steering and excellent visibility through a welded mesh guard with an optional removable platform available. The Hydraulic hand pump is sturdy and compact to fit through standard doors. The forks are raised by manual hydraulic hand pump operation and released by a lever situated on the handle. The unit has two (2) rigid and two (2) swivel wheels standard.

  • Stacker design meets the most challenging tasks
  • Unique design is maintenance free and easy to use
  • Full height push handle allows for easy steering
  • Rolls on smooth casters for stable maneuvering
Dimensions: 27.375"W x 60.25"L x 78"H Sell UOM: EA-Each Color: Black / Yellow
Material: Steel UPC: 691215079372 GTIN: 00691215079372
Warranty: -- Shipping Weight: 570 Quickship Item? --
Can It Ship UPS? -- Option? N Origin: China
Assembly: Assembled Packaging: BASE_UNIT_OR_EACH Drawing Required? Y
Uniform Capacity (lb.): 2000 Service Range (in.): 3-3/4 to 63 Fork Length (in.): 42-1/8
Lift per Handle Pump (in.): 3/4 Straddle Leg Minimum (in.): 34 (I.D) Straddle Leg Maximum (in.): 50 (I.D)
Fork Adjustment Minimum (in.): 6 (O.D) Fork Adjustment Maximum (in.): 24 (O.D) Rear Caster Quantity/Diameter/Width (in.): (2) 7 x 2
Rear Caster Type: Swivel with Brake Front Caster Quantity/Diameter/Width (in.): (2) 4 x 2-29/32 Front Caster Type: Rigid
Individual Fork Width (in.): 4 Horizontal Load Center (in.): 24
