Model Details
This Galvanized winch operated truck Jib crane lifts items from ground to truck bed height, then rotate into cargo area. Includes telescopic boom design with manual hydraulic hand pump to pivot boom up and down. Manual cable winch to lift and lower loads. Unit comes with one grab hook, one chain slot lock, and one sling hook with latch. Unit is designed for vertical lifting only. Do not use unit for lifting personnel or overhead lifting.
Uniform Cable Winch Capacity (lb.): 500 | Extended Fixed Hook Capacity (lb.): 1,000 | Extended Usable Reach (in.): 52 |
Extended Maximum Hook Height (in.): 97 | Extended Minimum Hook Height (in.): Zero | Retracted Fixed Hook Capacity (lb.): 2,000 |
Retracted Usable Reach (in.): 31 | Retracted Maximum Hook Height (in.): 86 | Retracted Minimum Hook Height (in.): 13-1/2 |
Overall Cable Length (ft.): 32 | Usable Cable Length (ft.): 24 | Cable Diameter (in.): 3/16 |
Mounting Plate Length (in.): 11 | Mounting Plate Width (in.): 11 | Base Height (in.): 11-1/2 |
Rotation (degrees): 360 | Piston Stroke (in.): 16-3/8 | Piston Stroke Per Pump (in.): 1/16 |
Cable Retracts/Extension Per Crank (in.): 1-1/2 | Number of Cranks to Retract/Extend Cable: 72 |
Details For Model: WTJ-4-G |
|||||||||||||||||||||||||||||||||||||
Galvanized Steel Winch Truck Jib Crane 52 In. Reach 1,000 Lb. Extended Capacity GrayThis Galvanized winch operated truck Jib crane lifts items from ground to truck bed height, then rotate into cargo area. Includes telescopic boom design with manual hydraulic hand pump to pivot boom up and down. Manual cable winch to lift and lower loads. Unit comes with one grab hook, one chain slot lock, and one sling hook with latch. Unit is designed for vertical lifting only. Do not use unit for lifting personnel or overhead lifting.
|
|||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||
